Yuken Type PV2R1-14-F-RAA-41 Hydraulic Vane Pump

Brand: Yihe

Product origin: China

Delivery time: 10-30days

Supply capacity: 300pcs/day

Model:PV2R1-14-F-RAA-41
Max Displacement: 26.4 ml/rev
Max Working Pressure: 24 Mpa
Shaft Speed Range: 600-2800 r/min
Rotation: Right and Left From Shaft End
Control Type: DOSING PUMP
Product Type: Vane Pump
WhatsApp: +86 13825579382
Email: Info vanepump382@gmail.com

Download:

Yuken Type PV2R1-14-F-RAA-41 Hydraulic Vane Pump

Yuken PV2R1-14

Show details

PV2R1-14-F-RAA-41

Simple maintenance and efficient operation

Yuken Hydraulic Vane Pump

High quality is more assured

Yuken PV2R1-14

Professional design, wear-resistant and pressure-resistant

PV2R1-14-F-RAA-41

Product feature:

1. High efficiency: The use of advanced design and manufacturing process, with high volumetric efficiency and mechanical efficiency. This can not only reduce energy consumption, but also improve production efficiency.
2. Long life: wear resistance and corrosion resistance have been significantly improved, with a long service life. This helps reduce maintenance costs and improve equipment reliability.
3. Wide applicability: suitable for a variety of hydraulic systems and industrial equipment, such as injection molding machines, die casting machines, hydraulic presses, etc. They can meet the needs of different fields and working conditions, and have high universality and interchangeability.
4. Easy maintenance: Vane pump design focuses on easy maintenance, such as easy to remove and replace the blade and other components. This helps to reduce maintenance time and costs and improve the maintainability of the equipment.
5 Good control performance: with stable flow and pressure output, accurate control can be achieved. This helps to improve the level of automation and production quality of the equipment.

Product parameters

Yuken Hydraulic Vane Pump


Pipe Flange Kits

Pipe flange kits are available.When ordering,specify the kit number from the table below.

Pump
Model
Numbers
Name
of
Port
Pipe Flange Kit Numbers
Threaded ConnectionSocket Welding★1Bult Welding
Japanese
Standard"JIS"
European
Design
Standard
          ★2
N. American
Design
Standard
Japanese
Standard"JIS"
European
Design
Standard
          ★2
N. American
Design
Standard
Japanese
Standard"JIS"
European
Design
Standard
          ★2
N. American
Design
Standard
PV2R1SuctionF5-08-A-10F5-08-A-1080F5-08-B-10F5-08-B-1090F5-08-C-10F5-08-C-1090
DischargeF5-04-A-10F5-04-A-1080F5-04-B-10F5-04-B-1090F5-04-C-10F5-04-C-1090

1.For the brands of anti-wear type water-glycols,see the item of "Hydraulic Fluids" on page 160.

2.If PV2R3-116 is used at speed above 1700 r/min,the suction pressure is limited to 0 kPa(0 in. Hg.).

3.If PV2R4-237 is used at speed above 1700 r/min,the suction pressure is limited to-13 kPa(3.94 in. Hg.vacuum).

4.If phosphate ester or water containing fluids are used,the maximum speed is limited to 1200 r/min.

5.For starting at low speed,the maximum viscosity is limited.For details,see the tiem of"Hydraulic Fluids" on page 160.

6.For pressure above 16 MPa(2320PSI),raise the speed over 1450r/min


Instructions for use

To protect your rights please read the following carefully

Pump Start-up Procedure
Preparation Prior to Start-up
The reservoir and circuit should be clean and free of dirt and debris prior to filling with fluid.
Circuit Cleanup
The reservoir should be charged with filtered hydraulic fluid. The fluid level should be sufficient to prevent vortexing at the suction connection to the pump inlet. It is good practice to clean the system by flushing and filtering, using an external slave pump.
Filling Pump and Removing Air
If the pump is mounted above the fluid level, it should be filled with fluid through the outlet port. If the pump is mounted below the fluid level, the pump outlet fitting (or other downstream fitting or plug) can be loosened to allow fluid to displace the air. It may be necessary to loosen the fill cap on the reservoir to allow the fluid to flow freely. When a solid stream of fluid with no observed air begins to drain through the loosened fitting, the fitting should be retightened. An air bleed valve in the outlet circuit is also recommended to remove trapped air. If such a device is used, the pump should be filled with fluid before start-up. In some cases, it may be possible to prime the pump by running the engine starter for five to ten seconds with the throttle and/or ignition switch in the "off" position. It will be necessary to loosen a fitting or plug in the pump outlet to allow air to escape.
Pump Start-up
All controls should be placed in the neutral position so the pump is unloaded when started. Start the engine and run at low idle. Once the pump is started, it should prime and pump within a few seconds. If it does not, make sure there are no restrictions between the reservoir and the inlet to the pump, and that there are no air leaks in the inlet line and connections.  Also, make sure that trapped air can escape from the outlet. Run at low engine idle for approximately five minutes. Then, while observing the reservoir fluid level, operate the implements. Extend all actuators to maximum safe limits to completely fill the system with fluid. Do not run with the fluid level below the "low" limit. Add fluid to the reservoir to bring the fluid to the proper fill level.

Yuken PV2R1-14

Company Profile

PV2R1-14-F-RAA-41

We are Guangzhou Yisheng Machinery Equipment Co.,Ltd., which located in Foshan City, Guangdong Province, China. We have R&D department with about 5-10 engineers and designers. Our factory have over 100 skilled employees, our production facility have many advanced manufacturing equipments and testing equipments, such as numerical control lathe, the processing center, CNC milling machine, special CNC grinding machine, double grinding machine, automatic 3D measuring instrument, etc..


Our main products are hydraulic variable displacement vane pump, double pump, HVP high pressure variable displacement vane pump, PV2R1 & PV2R2 series,V&VQ series,T6&T7 series, SQP series and VQ series of fixed displacement vane pump and electrical motors for hydraulic application.


Our products are widely used for industrial machinery, NC lathe machine, shoe machinery, wood working machines, plastic machines, construction machines and various hydraulic system machinery. We also able to supply the customized products and services as per your spec. ,we are looking forward to cooperating with your company sincerely.

Yuken Hydraulic Vane Pump

Why choose us

1.The company established more than 10 years, old brand, worthy of trust,Has more than 1000k+ followers

2.The company's product category is complete, also have a variety of accessories to provide.

3.All products have been passed strict quality test before shipment, make sure high quality.

4.24H customer service,Please feel free to contact me if you have any questions.

5.One-year warranty, we have professional and technical personnel for docking, product quality is hard, and after-sales are guaranteed. After the one-year warranty is over, we can provide maintenance services for customers (this requires a fee).

Yuken PV2R1-14

FAQ

Q: Are you trading company or manufacture?

A: We are factory

Q: How long is your delivery time?

A: Gernally it is 1-2days if the goods are in stock.It is 5-7days if the goods no stock.It is subject to order quantity.

Q: Do you provide sample,Is it free or extra?

A: We are willing to provide samples to test quality first, it is not for free because it is high value products. But sample cost can return in bulk order.

Q: What is the terms of payment?

A: 100% deposit or 30% deposit, 70% before shippment.

Q: How long is the warranty?

A: We offer 12 months warranty.

PV2R1-14-F-RAA-41

PV2R1-6-F-RAA   PV2R1-8-F-RAA   PV2R1-10-F-RAA

PV2R1-12-F-RAA   PV2R1-14-F-RAA   PV2R1-17-F-RAA

PV2R1-19-F-RAA   PV2R1-23-F-RAA   PV2R1-25-F-RAA

PV2R1-28-F-RAA   PV2R1-31-F-RAA
