The Professional Guide to Denison T6CR Series Rear Drive Vane Pumps
Introduction
In modern hydraulic engineering, space-saving and system flexibility are the keys to efficiency. When your application requires multiple independent flow sources but has limited motor space, the Denison T6CR series provides the ultimate solution. Known for its unique rear drive capability, the T6CR allows for a secondary pump to be mounted directly to its back, creating a high-performance tandem configuration that powers complex machinery with ease.
The T6CR Advantage: Expand Your System Power
The T6CR is more than just a single vane pump. It features a heavy-duty rear drive train that can drive an additional T6C or T6D pump. This "piggyback" design is ideal for systems requiring auxiliary functions like cooling, filtration, or secondary actuator control. Engineered with Denison's signature pin-type vane technology, the T6CR handles continuous pressures up to 240 bar, ensuring consistent performance even in the most demanding industrial environments.
Reliability Through Comprehensive Testing
Choosing a replacement pump requires technical certainty. Every T6CR unit we provide undergoes a rigorous full-load performance test. We verify the volumetric efficiency, pressure stability, and the mechanical integrity of the rear drive coupling. This ensures that your tandem setup will operate with zero cross-interference and maximum torque delivery from day one.
Denison T6CR Series Model Lineup
We provide 100% interchangeable "drop-in" replacements for the entire T6CR range. Our precision manufacturing ensures that all mounting dimensions and flow characteristics match the original Denison Parker standards exactly.
Technical Specifications: T6CR Series Selection Matrix
| Model Code | Displacement (ml/rev) | Max. Pressure (bar) | Max. Speed (rpm) | Mounting Standard |
| T6CR-031 | 99.1 | 240 | 2500 | SAE B 2-Bolt |
| T6CR-025 | 79.3 | 240 | 2500 | SAE B 2-Bolt |
| T6CR-020 | 63.8 | 240 | 2500 | SAE B 2-Bolt |
| T6CR-014 | 46.0 | 240 | 2500 | SAE B 2-Bolt |
| T6CR-010 | 34.1 | 240 | 2500 | SAE B 2-Bolt |
| T6CR-006 | 21.3 | 240 | 2500 | SAE B 2-Bolt |
| T6CR-003 | 10.8 | 240 | 2500 | SAE B 2-Bolt |
The Factory-Direct Solution
By partnering directly with a specialized manufacturer, you bypass the long lead times of original equipment suppliers. Our deep inventory of T6CR cartridge kits and rear drive components ensures that your custom tandem configurations are assembled and tested rapidly, keeping your project's downtime to a minimum.
Conclusion
Unlock the full potential of your hydraulic circuit with the T6CR series' unique expansion capabilities. Whether you are building a new machine or repairing a tandem unit, our engineering team is ready to provide the technical support and high-performance pumps you need.
