High Pressure, Silent Power: The Definitive Guide to Yuken PV2R1 Series Vane Pumps
Introduction
In the demanding world of industrial hydraulics—where injection molding machines and metal shears operate around the clock—system pressure stability is the pulse of productivity. The Yuken PV2R1 series has long been the industry's first choice for high-pressure, low-noise performance. At YHDE, we leverage over 9 years of specialized manufacturing expertise in our Foshan facility to provide 100% interchangeable PV2R1 solutions. We don't just supply pumps; we provide the reliability your machinery needs to eliminate unplanned downtime at factory-direct pricing.
The PV2R1 Advantage: Engineering for 210 Bar
Most standard vane pumps struggle once system pressure exceeds 175 bar. The PV2R1 series is uniquely engineered to handle continuous pressures up to 210 bar, making it a "heavy-duty" specialist. By utilizing a high-performance cartridge design, these pumps minimize internal leakage and maximize volumetric efficiency. At YHDE, we ensure every "drop-in" replacement matches these original Yuken specifications exactly, allowing you to restore machine power without costly modifications.
Reliability Through 100% Performance Testing
We understand that technical certainty is the highest priority for B2B buyers. Every PV2R1 unit produced by YHDE undergoes a rigorous full-load performance test on our professional testing stands. We verify flow rates, pressure holding, and noise decibels to ensure that the pump you receive is ready for immediate, high-load industrial use. This commitment to quality is what drives our 2026 vision of being your primary hydraulic partner.
Comprehensive PV2R1-F-RAA-41 Lineup
Our inventory supports the entire range of PV2R1 displacements, all featuring the standard F-RAA-41 configuration (Flange mounting, Right-hand rotation, Standard porting). Whether you need a compact flow for precision control or high-volume delivery, YHDE is ready to ship:
Precision Low-Flow Models: [PV2R1-6-F-RAA-41], [PV2R1-8-F-RAA-41], [PV2R1-10-F-RAA-41], and [PV2R1-12-F-RAA-41].
Mid-Range Versatility: [PV2R1-14-F-RAA-41], [PV2R1-17-F-RAA-41], [PV2R1-19-F-RAA-41], and [PV2R1-23-F-RAA-41].
High-Volume Powerhouse: [PV2R1-25-F-RAA-41], [PV2R1-28-F-RAA-41], and the flagship [PV2R1-31-F-RAA-41].
Technical Specifications: PV2R1 Series Performance Matrix
| Model Code | Displacement (ml/rev) | Max. Pressure (bar) | Max. Speed (rpm) | Min. Speed (rpm) |
| PV2R1-6 | 6.0 | 210 | 1800 | 750 |
| PV2R1-10 | 10.0 | 210 | 1800 | 750 |
| PV2R1-14 | 14.0 | 210 | 1800 | 750 |
| PV2R1-19 | 19.0 | 210 | 1800 | 750 |
| PV2R1-25 | 25.0 | 210 | 1800 | 750 |
| PV2R1-31 | 31.0 | 210 | 1800 | 750 |
The YHDE Direct-Factory Advantage
Sourcing directly from our Foshan factory eliminates middleman markups and grants you direct access to 9+ years of technical heritage. We maintain deep stocks of PV2R1 cartridge kits to ensure that if maintenance is required, your machine's "heart" can be restored in hours, not weeks.
Conclusion
Achieve the pressure your high-cycle systems demand with the verified quality of YHDE’s Yuken PV2R1 series. Our engineering team is available to confirm your model specifications and provide a technical quote today.
