Heavy-Duty Performance: The Power of Tokimec SQP32-45 Series High-Flow Double Vane Pumps
Introduction
In the world of high-output industrial machinery—from large-scale plastic injection molding to heavy-duty hydraulic presses—power density and noise control are critical. The Tokimec SQP32 series (Tokyo Keiki) is the industry benchmark for delivering massive flow rates with ultra-low noise signatures. At YHDE, we leverage 9+ years of specialized manufacturing expertise to provide 100% interchangeable SQP32-45 solutions that keep your factory running at peak efficiency.
The SQP32-45 Combination: A High-Flow Force
The SQP32 configuration integrates a high-displacement Frame 3 front section with a versatile Frame 2 rear section. By using a standard 45 USgpm front section, this series provides the primary power required for fast machine cycles while allowing for a customized secondary flow (from 10 to 25 USgpm) to handle auxiliary functions like core pulling or cooling.
Why YHDE is the Trusted Choice for 2026 and Beyond
As we work toward our 2026 vision of providing premium hydraulic solutions globally, our focus remains on "Direct-from-Factory" reliability. Every SQP32-45 unit manufactured in our Foshan facility undergoes a full-load performance test on our professional testing stands to ensure 100% compatibility and zero-leakage performance before shipment.
We offer precision "drop-in" replacements for the following SQP32-45 configurations:
Optimized Precision: [SQP32-45-10-86CC], [SQP32-45-12-86CC], and [SQP32-45-14-86CC] for systems requiring fine-tuned auxiliary control.
Balanced Industrial Power: [SQP32-45-15-86CC], [SQP32-45-17-86CC], and [SQP32-45-19-86CC] for general-purpose high-flow automation.
Maximum Output: [SQP32-45-21-86CC] and the flagship [SQP32-45-25-86CC] for the most demanding multi-circuit hydraulic applications.
Technical Specifications: SQP32-45 Series Selection Table
| Model Code | Front Flow P1 (USgpm) | Rear Flow P2 (USgpm) | Displacement P1/P2 (ml/r) | Max. Pressure (bar) |
| SQP32-45-10 | 45 | 10 | 142.0 / 33.0 | 175 |
| SQP32-45-14 | 45 | 14 | 142.0 / 45.0 | 175 |
| SQP32-45-17 | 45 | 17 | 142.0 / 55.0 | 175 |
| SQP32-45-21 | 45 | 21 | 142.0 / 67.0 | 175 |
| SQP32-45-25 | 45 | 25 | 142.0 / 79.0 | 175 |
Technical Advantage: The "86CC" Configuration
The 86CC specification is the most widely adopted industrial standard, featuring an SAE C 2-Bolt Flange with a Straight Keyed Shaft. The "CC" porting ensures that both discharge ports are oriented 90 degrees counter-clockwise from the inlet, allowing for clean and efficient piping in tight machine cabinets.
Conclusion
Don't let original OEM lead times or high costs slow your production. Partner with YHDE for factory-direct SQP32-45 series pumps that match the original Tokimec specifications in every dimension.
