SQP211-19-14-2-86CCC2-18 Triple Vane Pump | Tokimec Replacement | YHDE
Brand: YIHE
Product origin: China
Delivery time: 5-30days
Supply capacity: 7pcs/5day
High-precision SQP211-19-14-2-86CCC2-18 triple hydraulic vane pump, 100% interchangeable with Tokimec (Tokyo Keiki). Factory-direct from YHDE with 9+ years of manufacturing expertise. Features ultra-low noise and 100% performance testing. Fast shipping available. Get a quote!
SQP211-19-14-2-86CCC2-18 Triple Vane Pump | Tokimec Replacement | YHDE
Product Overview
The SQP211 Series is a specialized triple fixed displacement vane pump designed to provide three independent flow sources from a single drive shaft. This configuration significantly reduces installation space and simplifies complex hydraulic circuits. The SQP211-19-14-2-86CCC2-18 model is engineered for high-precision machine tools and industrial automation where multiple actuators must be powered simultaneously with minimal noise.
As a specialized manufacturer with over 9 years of expertise, YHDE produces the SQP triple series to be 100% interchangeable with Tokimec (Tokyo Keiki) standards. Our pumps serve as perfect "drop-in" replacements, matching all original performance curves and mounting dimensions.
Core Features & Benefits
Space-Saving Triple Configuration: Integrates three pump sections (Frame 2, Frame 1, and Frame 1) into a single compact housing, reducing the number of motors and couplings required.
Ultra-Low Noise Operation: Specifically designed for indoor factory environments, utilizing Tokimec-style internal geometry to minimize pressure ripples and vibration.
Multi-Circuit Efficiency: Delivers three distinct GPM flows (19, 14, and 2), allowing for synchronized control of various hydraulic functions within a single system.
100% Interchangeability: Direct replacement for Tokimec SQP211-19-14-2-86CCC2-18. No modifications to existing piping or SAE mounting are needed.
Durable Service Life: Built with high-strength materials and precision-finished components to withstand continuous industrial duty cycles.
Technical Specifications
| Parameter | Specification (P1 / P2 / P3) |
| Model Code | SQP211-19-14-2-86CCC2-18 |
| Compatibility | 100% Tokimec SQP Series |
| Displacement P1 (19) | 19 USgpm (at 1200 rpm) |
| Displacement P2 (14) | 14 USgpm (at 1200 rpm) |
| Displacement P3 (2) | 2 USgpm (at 1200 rpm) |
| Max. Pressure | 175 bar (2500 PSI) |
| Mounting Standard | SAE B 2-Bolt Flange |
| Shaft Type (86) | Heavy-Duty Straight Keyed |
| Rotation | Right Hand / Clockwise |
Why Source From YHDE Hydraulics?
Direct Factory Manufacturer: Benefit from factory-direct pricing and technical support based in Foshan.
9+ Years of Specialized Expertise: We focus exclusively on high-quality compatible vane pumps for global brands.
100% Performance Tested: Every SQP211 unit undergoes a rigorous full-load pressure and flow test on our professional testing stands before shipment.
Complete Parts Support: We maintain a comprehensive stock of SQP cartridge kits for all three sections to ensure fast repairs and minimal downtime.
