SQP211-19-2-2-86CCC2-18 Triple Vane Pump | 100% Tokimec Replacement | YHDE
Brand: YIHE
Product origin: China
Delivery time: 5-30days
Supply capacity: 7pcs/5day
High-precision SQP211-19-2-2-86CCC2-18 triple hydraulic vane pump (19+2+2 GPM). 100% interchangeable with Tokimec. Ultra-low noise design, factory-direct from YHDE with 9+ years of expertise. Reliable quality and fast global shipping. Get a quote today!
SQP211-19-2-2-86CCC2-18 Triple Vane Pump | 100% Tokimec Replacement | YHDE
Product Overview
The SQP211 Series is a high-performance triple fixed displacement vane pump designed for systems requiring three independent hydraulic circuits from a single drive source. The SQP211-19-2-2-86CCC2-18 model integrates three pump sections (Frame 2 + Frame 1 + Frame 1) into one compact housing, making it ideal for precision machine tools and complex industrial automation where space and noise control are critical.
As a specialized manufacturer with over 9 years of expertise, YHDE produces the SQP series to be 100% interchangeable with Tokimec (Tokyo Keiki) standards. Our triple pumps provide a seamless "drop-in" replacement that matches all original performance curves and mounting dimensions.
Core Features & Benefits
Ultra-Low Noise Operation: Specifically engineered to minimize pressure ripples, ensuring exceptionally quiet performance even with three active circuits.
High Power Density: Delivers three independent flow sources (19 GPM, 2 GPM, and 2 GPM) from a single SAE-B mounting flange, reducing system complexity and footprint.
100% Interchangeability: Direct replacement for Tokimec SQP211-19-2-2. No modifications to piping or mounting are required.
Rugged Industrial Build: Manufactured with high-strength alloys and precision-finished internal components to ensure a long service life in continuous duty cycles.
Ease of Maintenance: Utilizes modular cartridge kits for each section, allowing for rapid field service and reduced downtime.
Technical Specifications
| Parameter | Specification (P1 / P2 / P3) |
| Model Code | SQP211-19-2-2-86CCC2-18 |
| Compatibility | 100% Tokimec SQP Series |
| Front Flow (19) | 19 USgpm (at 1200 rpm) |
| Middle Flow (2) | 2 USgpm (at 1200 rpm) |
| Rear Flow (2) | 2 USgpm (at 1200 rpm) |
| Max. Pressure | 175 bar (2500 PSI) |
| Mounting Standard | SAE B 2-Bolt Flange |
| Shaat Type (86) | Heavy-Duty Straight Keyed |
| Outlet Positions | All 90 degrees CCW from inlet (CCC) |
Detailed Model Code Analysis
SQP211: Triple Vane Pump (Series 2 + 1 + 1).
19-2-2: Displacement for Front, Middle, and Rear sections in USgpm.
86: Shaft type (Straight keyed).
CCC: Outlet port positions for all three sections.
18: Design sequence.
Why Source From YHDE Hydraulics?
Direct Factory Support: Work directly with a Foshan-based manufacturer with 9+ years of focused industry experience.
100% Performance Tested: Every triple pump unit undergoes a rigorous full-load pressure and flow test on our professional testing stands before shipment.
Global Compatibility: Our products are engineered to provide reliable, cost-effective replacements for Tokimec, Vickers, Denison, and Yuken.
Deep Inventory: We maintain a comprehensive stock of SQP series cartridge kits for all frame sizes to ensure fast worldwide delivery.
